Ningbo Fenghua Bolong Machinery Manufacturing Co., Ltd. Thov koj xav tias dawb mus yuav cov bushing ruaj khov ua nyob rau hauv Suav teb nov los ntawm peb lub hoobkas. Tag nrho cov khoom customized yog nrog cov khoom zoo thiab cov nqi sib tw.
Core Zoo
Split Design kom yooj yim installation- Lub axial qhov txuas txuas ntxiv tso cai rau radial compression thaum lub sij hawm ntxig, ua rau kev teeb tsa rau hauv qhov chaw kaw qhov tsis tau nias lossis yuav tsum tau sib dhos disassembly. Tabs los yog notches ntawm kev sib cais xaus tuaj yeem muab tshem tawm nrog cov txheej txheem kev pabcuam.
Tus kheej -Tshuaj Thaum Tso Tawm- Lub caij nplooj ntoos hlav- rov qab yam ntxwv ntawm cov khoom siv bushing - feem ntau yog 0.05-0.15mm radial expansion tom qab ntxig - tsim kev sib koom tes zoo nrog cov phab ntsa bore. Qhov kev ntsuas tus kheej no tshem tawm qhov xav tau ntawm cov nplaum nplaum, staking, lossis cov khoom siv kho tshuab hauv ntau daim ntawv thov.
Txias Extruded Core Structure- Cov cylindrical feem ntawm bushing yog tsim los ntawm txias extrusion, kom ntseeg tau raws li phab ntsa tuab, qhov tseeb qhov tseeb, thiab ua hauj lwm - hardened nto hardness. Cov txheej txheem extrusion khaws cia tsis muaj kev cuam tshuam cov nplej, ua rau qaug zog lub zog nyob rau hauv cyclic loading.
Precision Bore Control- Internal diameters yog tswj kom nruj tolerances - feem ntau H7 los yog zoo dua - xyuas kom meej haum nrog pins, shafts, los yog fasteners hla bushing. Nto roughness yog tswj los txo kev sib txhuam thiab hnav ntawm rotating los yog zawv zawg ntsiab.
Khoom siv yooj yim- Muaj nyob rau hauv siab - lub zog steel rau siab tshaj plaws load peev; aluminium alloys rau lub teeb yuag thiab corrosion kuj; thiab lead- dawb tooj liab alloys kom txo kev sib txhuam. Txhua yam khoom raug muab sib xyaw rau ib puag ncig kev teeb tsa tshwj xeeb thiab lub voj voog thauj khoom.
Qhov sib npaug Geometry- Lub qhov axial yog txiav rau qhov dav tswj - feem ntau 1-3mm - nrog square lossis radiused xaus raws li tau teev tseg. Qhov chaw qhov chaw txheeb ze rau lub bore axis yog tuav kom nruj positional tolerances los xyuas kom meej tus cwj pwm compression uniform thiab zoo ib yam ntsia ntev.
Kev tiv thaiv corrosion- Cov qauv hlau txais zinc plating, phosphating, lossis Dacromet txheej. Aluminium versions muaj anodized lossis chem- zaj duab xis coated rau MIL lossis OEM specifications. Kev kuaj ntsev ntsev yog muab rau kev siv tau.
Technical Specifications
|
Parameter |
Paub meej |
|
Khoom npe |
Split Bushings - Precision Slotted Cylindrical Cheebtsam |
|
Khoom siv |
Siab -lub zog steel, aluminium alloy (A6061, A7075), tooj liab alloy (xaiv) |
|
Kev tsim khoom |
Txias extrusion → qhov txiav (xaim EDM los yog milling) → qhov deburring |
|
Qhov Loj |
OD . 8-80mm; ID. 5-65mm; Ntev 8-80mm (Customizable) |
|
Tolerances |
OD ± 0.05 hli; ID H7 (los yog zoo dua); Qhov dav dav ± 0.10mm |
|
Txhim kho Expansion |
0.05-0.15mm radial expansion (khoom-dependent) |
|
Kev kho saum npoo |
Zinc plating, phosphating, Dacromet, anodizing, chem{0}} zaj duab xis |
|
Cov Txheej Txheem Zoo |
IATF 16949 tau ntawv pov thawj kev tsim khoom |
Kev tsim khoom
|
Theem |
Cov haujlwm tseem ceeb |
|
Khoom Prep |
Coil / bar pub → txias taub hau lossis extrusion slug txiav |
|
Txias Extrusion |
Multi- chaw nres tsheb qub → extrusion mus ze -net shape |
|
Qhov txiav |
Precision hlau EDM lossis CNC milling → axial qhov txiav |
|
Nto & kawg |
Deburring → kho deg → qhib dav check |
Kev Tswj Xyuas Zoo
Daim ntawv thov Scenario
Shock Absorber Installation & Service
Split bushings yog siv rau ntawm qhov chaw sib txuas ntawm qhov poob siab absorber qis bracket thiab ncua kev tswj tuav caj npab los yog qag vaj tse. Txoj kev sib cais tso cai rau hloov bushing yam tsis muaj disassembling tswj caj npab lossis qag - tsuas yog compress lub phua bushing, ntxig rau hauv lub bore, thiab tso rau nws tus kheej - xauv tuav. Qhov no feature yog tshwj xeeb tshaj yog muaj txiaj ntsig nyob rau hauv cov kev pab cuam tom qab muag, txo qis kev kho lub sijhawm ua haujlwm.
Kev hloov ceev ntawm Chassis Suspension Bushings
Hauv kev tswj caj npab bushings, stabilizer txuas bushings, thiab lwm yam chassis ncua kev kawm ntawv, kev faib bushing tsim ua rau ntawm - hloov chaw yam tsis muaj hydraulic xovxwm. Rau cov chaw pabcuam uas tsis muaj cov khoom siv xovxwm, cais bushings muaj lwm txoj hauv kev uas yuav tsum tsis muaj cov cuab yeej tshwj xeeb thaum tswj kev tuav ruaj khov thiab clamping quab yuam.
Hnyav-Kev hloov kho tsheb thauj mus los ua haujlwm hnyav
Nyob rau hauv lub equalizing beam suspension systems ntawm hnyav - cov tsheb thauj khoom thiab cov khoom siv tsim kho, kev sib cais bushings yog siv rau kev sib tsoo pas nrig thiab sib npaug ntawm txoj kab sib txuas. Tus kheej -locking yam ntxwv ntawm kev sib cais tsim tswj txoj hauj lwm stability nyob rau hauv vibration thaum tso cai sai disassembly thiab reinstallation thaum lub sij hawm kev pab cuam.
Kev Pabcuam Kev Cai
Tsim kev sab laj
Kev ntsuam xyuas engineering ntawm kev teeb tsa bore geometry, compression pub, thiab cov kev cai thauj khoom
Kev cai loj
OD, ID, qhov ntev, thiab qhov dav rau koj cov duab kos
Kev xaiv khoom
Siab -lub zog steel rau hnyav hnyav; aluminium rau qhov hnyav txo; tooj liab alloy rau kev sib txhuam qis
Qhov geometry
Txheem axial qhov; muab kev tshem tawm tabs; square lossis radiused xaus
Kev kho deg rau koj spec
Zinc plating, phosphating, Dacromet, anodizing, lossis chem- zaj duab xis
Qauv validation txhawb
Prototype kom muaj nuj nqis rau kev sim sib dhos thiab clamp load pov thawj
Txawm hais tias koj xav tau steel split bushings rau kev poob siab absorber mounting, aluminium split bushings rau automotive lightweighting, precision split bushings nrog nruj bore tolerances, los yog txias extruded split bushings nrog zoo ib yam ntsia cov yam ntxwv - peb pab neeg engineering txhawb koj qhov project los ntawm lub tswv yim los ntawm validation thiab ntim ntau lawm.
